| Part Number | Dimension (mm) | ||
| Dc1 | Dc | Dw | |
| TV1023 | 10 | 23 | 2 |
| TP1024-1 | 10 | 24 | 2 |
| TP1224 | 12 | 24 | 2 |
| TP1226B | 12 | 25.8 | 2 |
| TV1226 | 12 | 26 | 2 |
| TP1427 | 14 | 27 | 2 |
| TV1528 | 15 | 28 | 2 |
| TP1532-1 | 15 | 32.3 | 2 |
| TP1629 | 16 | 29 | 2 |
| TP1730 | 17 | 30 | 2 |
| TV1734 | 17 | 34 | 2.5 |
| TP1740 | 17 | 40 | 2.5 |
| TP1831 | 18 | 31 | 2 |
| TP2035-1 | 20 | 35 | 2 |
| TP2132D | 20.9 | 32 | 2 |
| TP2234 | 21.9 | 34 | 2 |
| TP2237-1 | 22 | 37 | 2 |
| TP2236A-1 | 22.2 | 36.1 | 1.984 |
| TP2542 | 25 | 42 | 2 |
| TV2639-1 | 26 | 38.66 | 2 |
| TP2841C | 28 | 41 | 2 |
| TP2845 | 28 | 45 | 2 |
| TP2946A | 28.5 | 46.15 | 2 |
| TP2942A-1 | 28.9 | 42 | 1.984 |
| TP3047-1 | 30 | 47 | 2 |
| TP3249 | 32 | 49 | 2 |
| TP3445A | 33.5 | 45 | 2 |
| TP3552B | 34.65 | 52 | 2 |
| TP3558 | 34.65 | 58.4 | 2 |
| TP3558-1 | 34.65 | 58.4 | 2 |
| TP3855A | 38.15 | 55.29 | 1.984 |
| TP4058-1 | 39.6 | 58.1 | 3 |
| TP4060 | 40 | 60 | 3 |
| TP4168 | 41 | 68 | 9 |
| TP4262 | 42 | 62 | 3 |
| TV4562 | 45 | 62.19 | 1.984 |
| TP4556 | 45 | 56 | 2 |
| TP4565A | 45 | 65 | 3 |
| TP4668-2 | 46.4 | 68 | 3.5 |
| TV4971 | 49 | 70.65 | 1.984 |
| TP5070 | 50 | 70 | 3 |
| TV5273 | 52 | 72.6 | 1.984 |
| TP5578 | 55 | 78 | 3 |
| TP6085 | 60 | 85 | 3 |
| TP6280A | 62 | 80.25 | 2 |
| TP6590 | 65 | 90 | 3 |
| TV7092A | 70.03 | 92.37 | 3.175 |
| TP7095 | 70 | 95 | 4 |
| TP75100 | 75 | 100 | 4 |
| TP80105 | 80 | 105 | 4 |
| TP83114 | 82.68 | 114.3 | 9.525 |
| TP85110 | 85 | 110 | 4 |
| TP90120 | 90 | 120 | 4 |
| TP100135 | 100 | 135 | 4 |
