| Part Number | Dimension(mm) | |||
| d | F | D | B | |
| NKI5/12TV | 5 | 8 | 15 | 12 |
| NKI5/16TV | 5 | 8 | 15 | 16 |
| NKI6/12TV | 6 | 9 | 16 | 12 |
| NKI6/16TV | 6 | 9 | 16 | 16 |
| NKI7/12TV | 7 | 10 | 17 | 12 |
| NKI7/16TV | 7 | 10 | 17 | 16 |
| NKI9/12 | 9 | 12 | 19 | 12 |
| NKI9/16 | 9 | 12 | 19 | 16 |
| NKI10/16 | 10 | 14 | 22 | 16 |
| NKI10/20 | 10 | 14 | 22 | 20 |
| NKI12/16 | 12 | 16 | 24 | 16 |
| NKI12/20 | 12 | 16 | 24 | 20 |
| NKI15/16 | 15 | 19 | 27 | 16 |
| NKI15/20 | 15 | 19 | 27 | 20 |
| NKI17/16 | 17 | 21 | 29 | 16 |
| NKI17/20 | 17 | 21 | 29 | 20 |
| NKI20/16 | 20 | 24 | 32 | 16 |
| NKI20/20 | 20 | 24 | 32 | 20 |
| NKI22/16 | 22 | 26 | 34 | 16 |
| NKI22/20 | 22 | 26 | 34 | 20 |
| NKI25/20 | 25 | 29 | 38 | 20 |
| NKI25/30 | 25 | 29 | 38 | 30 |
| NKI28/20 | 28 | 32 | 42 | 20 |
| NKI28/30 | 28 | 32 | 42 | 30 |
| NKI30/20 | 30 | 35 | 45 | 20 |
| NKI30/30 | 30 | 35 | 45 | 30 |
| NKI32/20 | 32 | 37 | 47 | 20 |
| NKI32/30 | 32 | 37 | 47 | 30 |
| NKI35/20 | 35 | 40 | 50 | 20 |
| NKI35/30 | 35 | 40 | 50 | 30 |
| NKI38/20 | 38 | 43 | 53 | 20 |
| NKI38/30 | 38 | 43 | 53 | 30 |
| NKI40/20 | 40 | 45 | 55 | 20 |
| NKI40/30 | 40 | 45 | 55 | 30 |
| NKI42/20 | 42 | 47 | 57 | 20 |
| NKI42/30 | 42 | 47 | 57 | 30 |
| NKI45/25 | 45 | 50 | 62 | 25 |
| NKI45/35 | 45 | 50 | 62 | 35 |
| NKI50/25 | 50 | 55 | 68 | 25 |
| NKI50/35 | 50 | 55 | 68 | 35 |
| NKI55/25 | 55 | 60 | 72 | 25 |
| NKI55/35 | 55 | 60 | 72 | 35 |
| NKI60/25 | 60 | 68 | 82 | 25 |
| NKI60/35 | 60 | 68 | 82 | 35 |
| NKI65/25 | 65 | 73 | 90 | 25 |
| NKI65/35 | 65 | 73 | 90 | 35 |
| NKI70/25 | 70 | 80 | 95 | 25 |
| NKI70/35 | 70 | 80 | 95 | 35 |
| NKI75/25 | 75 | 85 | 105 | 25 |
| NKI75/35 | 75 | 85 | 105 | 35 |
| NKI80/25 | 80 | 90 | 110 | 25 |
| NKI80/35 | 80 | 90 | 110 | 35 |
| NKI85/26 | 85 | 95 | 115 | 26 |
| NKI85/36 | 85 | 95 | 115 | 36 |
| NKI90/26 | 90 | 100 | 120 | 26 |
| NKI90/36 | 90 | 100 | 120 | 36 |
| NKI95/26 | 95 | 105 | 125 | 26 |
| NKI95/36 | 95 | 105 | 125 | 36 |
| NKI100/30 | 100 | 110 | 130 | 30 |
| NKI100/40 | 100 | 110 | 130 | 40 |
